LCD monitor product features:
Professional narrow frame structure design, beautiful appearance.
The special industrial LCD panel has stable performance.
High brightness, high contrast, high definition, and strong sense of layering.
16.7M color really reproduces every detail of the picture.
Using the latest 3D digital filtering and 3D digital noise reduction technology, better light and color interference can be eliminated.
5ms fast response time, the picture is really not tailed;
Intelligent temperature control fan, environmental sound;
The service life is more than 60 thousand hours, and it can work continuously for 7*24 hours throughout the year.
All metal housing design, anti static, anti magnetic, anti-interference, no radiation;
Multi - level menu display function, more convenient manipulation;
Using VESA wall hanging standard, the installation is more convenient.
Rich interface to meet the needs of many applications.
Product specification table:
液晶监视器尺寸 | 21.5寸液晶监视器 | |
液晶监视器型号 | GWX-2204 | |
面 板 参 数 | 面板类型 | 21.5”LED Panel |
显示尺寸(mm) | 477(W)*268.5(H) | |
显示比例 | 16:10 | |
背光类型 | LED | |
分 辨 率 | 1920*1080 | |
显示色彩 | 16.7M | |
亮度 | 300cd/m2 | |
对比度 | 1000:1 | |
可视角度 | 178°/178° | |
响应时间 | 5ms | |
使用寿命 | 60000小时 | |
功 能 | 彩色制式 | PAL/NTSC/SECAM |
菜单语言 | 简体中文、繁体中文、英文多国语言 | |
操作方式 | 遥控器、线控 | |
输 入 输 出 接 口 | D-15 针RGB 输入(VGA) | 1 |
DVI输入 | 无 | |
HDMI输入 | 1 | |
色差(YUV)输入(YPbPR) | 1(BNC*3) | |
复合视频输入(AV) | 2(BNC*2) | |
S-VIDEO端子(YC) | 无 | |
复合视频输出(AV) | 1(BNC*1) | |
PC-AUDIO输入 | 1 | |
AV-AUDIO输入 | 1 | |
电 源 | 电源输入 | AC100-240V,50 /60HZ |
电源功耗 | ≤52W | |
待机功耗 | ≤3W | |
工 作 环 境 | 工作温度 | 0℃—50℃ |
存储温度 | -20℃-60℃ | |
工作湿度 | 10%-90% | |
存储湿度 | 10%-90% | |
产 品 相 关 | 安装方式 | 壁挂、桌面式等 |
产品尺寸 | 502*298.6*56(mm) | |
外观颜色 | 黑色 | |
外壳材质 | 金属 | |
产品认证 | ISO9001,3C等 | |
净重 | 5.6KG | |
